Applies to model airplane / Model car / robot
Torque: 5.5kg/cm (at 4.8V)
Speed: 0.22sec/60°(at 4.8V)
Working voltage: 4.8v-6v
Temperature: 0 Celsius Degree-60 Celsius Degree
Current: < 1000mA
Dimensions: 40.8 x 20 x 39.5 mm
This servo carries meso-position adjustment potentiometer(it can only be seen by peeling off the outer cover and circuit board). We can set high level pulse at 1.5ms to observe that whether servo stops rotating. If it doesn’t stop rotating, we keep adjusting the potentiometer until it does.
